Encoder, 1 pc, E60H20-8192-3-V-5-C
28.38 USD(tax included)
／51.08 USD (Excluding tax)
Sales unit: 1 piece
Application number: / Manufacturer: / Model number: m60415778957 / JAN code: / AS ONE / NAVIS Product number:
| Application number | |
|---|---|
| Manufacturer | |
| Model number | m60415778957 |
| JAN code | |
| Sales unit | 1 piece |
| Price | 28.38 USD (tax included) / 51.08 USD (Excluding tax) |
*Additional shipping fees will be charged for this product in Okinawa Prefecture, remote islands, some other areas, and mountain areas. Please note that we may not be able to deliver depending on the region. If we are unable to deliver your order after placing your order, Askul will contact you.
Please note the following points as this item is directly shipped.
- Additional shipping fees will be charged for this product in Okinawa Prefecture, remote islands, some other areas, and mountain areas. Please note that we may not be able to deliver depending on the region. If we are unable to deliver your order after placing your order, Askul will contact you.
- This product may not come with a delivery note issued by Askul. Customers who wish to receive a delivery note issued by Askul can print it out as a PDF file from the usage history on this site after receiving the product.
- It is not delivered in Askul cardboard or a bag.
- We cannot accept changes, cancellations, returns, or exchanges after the order has been placed due to the customer's convenience.
- If we discover after placing an order that the product cannot be delivered, we may cancel your order.
- If it becomes clear after placing your order that the item is temporarily out of stock, it will be delivered as soon as it becomes available.
This image is a representative image. Please check the specifications for details.
Stock: Slightly
Direct delivery product
Shipping charges for products from this shipping source will be borne by us.
58 USD (tax included)
/ 63.8 USD (Excluding tax)
Product details
Print product information
| Product features | Category Tachometers & Counters Condition No noticeable scratches or marks Shipping Included in price (by seller) From Miyagi |
||
|---|---|---|---|
| Manufacturer name | - | Brand name | - |
| remarks | [About returns] We cannot accept returns due to customer's convenience. | ||
| Product details |
E60H20-8192-3-V-5-C Manufactured by AUTONICS Quantity: 1 Used item 2 units in stock. Please comment if you wish to purchase multiple units. Type: Incremental, Resolution: 8192 Outer Diameter (mm): 60, Output Phase: A, B, Z Phase Control Output: Voltage Output, Power Supply Voltage (VDC): 5VDC ±5% Wiring Specification (m): Lead wire connector type, Shaft Type: Hollow Shaft Response Time: ≤1μs, Maximum Response Frequency: 300kHz Current Consumption: ≤80mA (no load), Insulation Impedance: ≥100MΩ (between all terminals and case, 500VDC mega standard) Withstand Voltage: 750VAC for 1 minute at 50/60Hz (between all terminals and case) Connection Method: Lead wire type Shaft Load: Radial: 5kgf / Thrust: 2.5kgf, Maximum Allowable Rotational Speed: 6000rpm Vibration Resistance: 10-55Hz (1 minute cycle), Double Amplitude: 1.5mm, 2 hours each in X, Y, Z directions Shock Resistance: ≤100G Environmental Temperature: -10 to 70℃ (non-freezing), Storage: -25 to 85℃ Environmental Humidity: 35 to 85%RH, Storage: 35 to 90%RH Protection Rating: IP50 (IEC standard) Wiring: φ5mm, 5P, Length: 2m, Shielded cable Accessories: Bracket Shaft Inner Diameter (mm): φ20 Click here for the manufacturer's site
